Intermatic

ET2125CP

Intermatic ET2125CP 24-Hour/365 Day 2-Circuit Electronic Control, 120-277 VAC, Indoor/Outdoor Plastic Enclosure

Intermatic ET2125CP 24-Hour/365 Day 2-Circuit Electronic Control, 120-277 VAC, Indoor/Outdoor Plastic Enclosure

$345.00 CAD
$345.00 CAD
Sale Sold out

In stock

Description

The ET2000 Series offers an easy-to-use interface, while still allowing to-the-minute scheduling capabilities for nearly any application. This series provides 50 holiday blocks with independent scheduling to ensure the loads are always in the proper ON/OFF state. This series also includes 96 ON/OFF events for even the most demanding schedules. The scheduling capabilities, configurable outputs, and a 100-hour backup without the need of batteries, make this series ideal for nearly any application. They come in standard 24-hour versions.

Features

  • 100-hour supercapacitor eliminates the need for batteries.
  • Up to 96 set points or events.
  • Up to 50 holiday blocks with schedule capabilities.
  • Automatic input voltage selection from 120 to 277 VAC, 60 Hz.
  • Additional mode of operation turns the ON/OFF buttons into 2-hour overrides.
  • Configurable outputs allow the control of various voltages and applications.
  • Relays incorporate zero-crossing technology to extend the life of the control.
  • Non-volatile EEPROM memory protects programming indefinitely.
  • LED compatible.
  • USB port makes transferring and saving of schedules easy.

Applications

  • Indoor Lighting Control
  • Machinery & Pump Controls
  • Timing/Scheduling ON/OFF

Documents

ET2125CP Technical Data Sheet
